Ranger 12V / 24V Cabin Fan

The Ranger Fan is a permanently mounted marine RV fan. It features an innovative gimbal design for 360° directional airflow across three-speed settings, providing unmatched comfort. For peace of mind, the fan puts minimal strain on batteries, drawing just 0.42A on its highest 12V setting, and is ultra quiet, with four auto-off options (3, 6, 9 and 12 hours) for a restful night’s sleep. The fan stows flat at 97mm deep.

Features:

Innovative gimbal design offers complete 360° airflow.
Three speeds with ultra quiet operation
Sleep in comfort with four auto-off timer settings (3, 6, 9, and 12 hours)
Long-life motor with low-power draw
Hard-wired to power supply
Easy installation. Secures to a baseplate which can be mounted to wall or ceiling
178mm (7") blade

Specifications:

Voltage: 12V or 24V auto sensing
Speed settings: 3 (Low / Medium / High)
Current Draw 12V: Low = 0.14A, Medium = 0.26A, High = 0.42A
Current Draw 24V: Low = 0.07A, Medium = 0.13A, High = 0.21A
Air flow volume (m3/hr): Low = 628, Medium = 910, High = 1231
Dimensions (mm): 242H x 312L x 97D
Motor lifespan: 4000+ hours
Warranty: 1 year
